VORTICE - VENTILADOR DE TECHO SERIE NORDIK ECO, BLANCO, SIN LUZ Y DISPOSITIVO DE MANDO, DIÁMETRO 90
• NOMINAL DIAMETER OF BLADES 900 MM.
• CUPS AND MOTOR COVERS MOLDED IN HEAT-RESISTANT POLYMER (ASA), MATT WHITE (RAL9016).
• EC (BRUSHLESS) MOTOR WITH SHAFT TURNING IN BALL BEARINGS, REVERSIBLE FUNCTION, ABLE TO GRANT HIGH PERFORMANCE THROUGHOUT THE OPERATING RANGE. INTEGRATED MOTOR DRIVER.
• 3 POWDER COATED SHEET STEEL BLADES, MATT WHITE (RAL9016).
• POWDER COATED STEEL CEILING ROD, MATT WHITE (RAL9016).
• ACCESSORIES BAG CONTAINING FIXING BOLTS FOR BLADES, CEILING HOOK AND RUBBER ANTI-VIBRATION WASHER.
• POSSIBILITY OF SPEED REGULATION BY POTENTIOMETER OR IR REMOTE CONTROL (OPTIONAL).
NORDIK ECO 90/36" 61060
ABSORBED CURRENT MAX (A): 0,26
ABSORBED POWER MAX (W): 27
BLADES DIAMETER: 914
FREQUENCY (HZ): 50
INSULATION CLASS: I°
MAX AMBIENT TEMPERATURE FOR CONTINUOUS OPERATION (°C): 45
VOLTAGE (V): 220-240
WEIGHT (KG): 7,5
AIRFLOW SPEED AT MAX SPEED (M/S): 2,88
DELIVERY MAX (M³/H): 9500
DELIVERY MAX (M³/MIN): 158,33
RPM: 250
SERVICE VALUE (M³/MIN)/W: 5,864
SOUND POWER LEVEL LW [DB(A)]: 45,6
SIZE A (MM): Ø 914
SIZE B (MM): Ø 237
SIZE C (MM): 535
